Display
Projection Systém    DLP Single 0.65" WXGA
Native Resolution   1280 x 800 pixels
Brightness    4000 ANSI Lumens
Contrast Ratio*    20,000:1
Aspect Ratio    Native 16:10 (5 aspect ratio selectable)
Light Source    Lamp
Picture mode    Presentation / Inforgraphic /Spreadsheet
Light Source life*   Normal mode: Typical 6,000 hours Eco mode: Typical 10,000 h


Dimension (mm)
Throw Ratio   1.55-1.7
Zoom Ratio    1.1x
Lens shift    NA
Keystone Adjustment    1D, +/- 30 degrees (V only)
Projection Offset    110% (Mode B)± 2.5%
Projection Size    60" ~ 150"
Built-in Speaker     10W

Security Bar,Kensington lock

Compatibility
Resolution Support    VGA(640 x 480) to WUXGA (1920x1200)
Horizontal Frequency    15K~102KHz
Vertical Scan Rate    23~120Hz
HDTV Compatibility    480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Video Compatibility     NA
Typical Power Consumption (100V)    270W
Standby Power Comsumption     Normal < 0.5Watts.
Power Supply     AC 100 to 240 V, 50/60 Hz
Product Dimensions (WxHxD)    296 (W) x 221 (D)x 129 (H) mm
Product Weight     2.3 kg

Operation Condition
Noise Level(Normal/Eco)     34/29dBA
Operating Temperature    0 ~ 40oC


Connectivity
HDMI 1.4
WXGA Lamp light source
RS232 In (D-sub 9pin, male)
BenQ SmartEco Energy Conservation
USB (Type A)
20,000:1 High contrast
Audio in/out
USB (Mini B)
Speaker (10W)
VGA in
IR Receiver (Front )
