Kingston FURY™ Renegade G5 PCIe 5.0 NVMe M.2 SSD is for high-power users, hardware enthusiasts and gamers ready for the latest Gen 5x4 performance. With raging speeds of up to 14,800MB/s read and 14,000MB/s write, its extreme performance boosts game and app load times and improves reaction time, while its exceptional design keeps it cool.

Form factor M.2 2280
Interface PCIe 5.0 x4 NVMe
Capacities2 1024GB, 2048GB, 4096GB
Controller SM2508
NAND 3D TLC
DRAM cache Yes
DirectStorage supported Yes
Sequential read/write1 1024GB – up to 14,200/11,000MB/s
2048GB – up to 14,700/14,000MB/s
4096GB – up to 14,800/14,000MB/s
Random 4K read/write1 1024GB - up to 2,200,000/2,150,000 IOPS
2048GB – 4096GB - up to 2,200,000/2,200,000 IOPS
Endurance (total bytes written)3 1024GB – 1.0PB
2048GB – 2.0PB
4096GB – 4.0PB
Power consumption4 1024GB – 0.27W avg / 6.6W @ 14.2G / 6.6W (MAX)
2048GB – 0.27W avg / 7.0W @ 14.7G / 7.0W (MAX)
4096GB – 0.27W avg / 7.1W @ 14.8G / 9.5W (MAX)
Storage temperature -40°C~85°C
Operating temperature 0°C~70°C
Dimensions 80mm x 22mm x 2.3mm
Weight 1024GB – 7.3g
2048GB-4096GB – 7.7g
Vibration operating 2.17G peak (7-800Hz)
Vibration non-operating 20G peak (20-1000Hz)
MTBF 2,000,000 hours
Warranty/Support5 Limited 5-year warranty with free technical support
