MSI Crosshair 16 Max HX E2WGXK-021XCZ/Core Ultra 9 275HX/32GB/1TB/RTX 5070, 12GB/16" QHD+165Hz OLED/Bez OS

Part No 9S7-265232-021
SKU Number
Website Name Crosshair 16 Max HX E2WGXK
Platform INTEL
Series Name Gaming
Segment Name CrosshairMax
Segment Name2 Crosshair16MaxHXE
Segment Name3 Crosshair16MaxHXE2WGXK
Model 2652
MKT Name Crosshair 16 Max HX E2WGXK
Entity MKT Name
MKT Spec Crosshair 16 Max HX E2WGXK-021XCZ
Chassis Color
Color ID3(BB)/Core_Black-Black-Black-Black
Color_Website Core Black
Chassis Material
A Side Metal
B Side Plastic
C Side Plastic
D Side Plastic
Display
Screen Size 16
Resolution IPS-Level QHD+
LCD Features GLARE
Screen Touch Non-touch
Frame Rate 165Hz
Response Time Tr+Tf 1ms
Color Range 100% DCI-P3 typ.
Screen Size_Website 16"
Pixel_Website QHD+(2560x1600)
Frame Rate_Website 165Hz Refresh Rate
Color Range_Website 100% DCI-P3(Typical)
Display Type_Website OLED
Peak Brightness (HDR Value) VESA DisplayHDR™ True Black 1000 Certified
Touch Feature_Website NA
Typical Brightness 500 nits
Typical Brightness Remark N/A
Eye Care Feature SGS Eye Care Display
CPU
CPU Type 24 CORE,4 CORE
CPU Core Name ARROW LAKE
CPU Number Core Ultra 9 275HX
CPU Basic Clock 2.7GHz
CPU Cores 24,4
NPU TOPS 13
CPU Core Name_Website N/A
CPU Number_Website Intel® Core™ Ultra 9 processor 275HX with Intel® AI Boost (NPU)
CPU Number_Website For GC Intel® Core™ Ultra 9 processor 275HX with Intel® AI Boost (NPU)
CPU Specification_Website 24 cores (8 P-cores + 16 E-cores), 24 threads, 36MB L3 cache, Max Turbo Frequency 5.4 GHz
Intel Evo Certified N/A
Chipset
Chipsets HM870
Chipset SoC_Website Intel® HM870
Discrete Graphics
GPU1 Vendor NVIDIA
GPU1 MKT Name GeForce RTX 5070
GPU1 Number RTX 5070
GPU1 MKT Name_Website NVIDIA® GeForce RTX™ 5070 Laptop GPU powers advanced AI with 798 AI TOPS
GPU1 Boost Clock_Website 2347MHzx Up to Boost Clock 115W Maximum Graphics Power with Dynamic Boost. *May vary by scenario
GPU1 Remark_Website N/A
CPU and GPU Combined Power
Combined Power_Website Max. 200W CPU-GPU Power with MSI OverBoost Technology.
OverBoost Ultra Remark_Website N/A
Scenario Remark_Website *Full Power CPU & GPU
Cooling
Thermal Cooler Boost
Fan 2
Fan Technology NA
Pipe 5
Vapor Chamber NA
Video Memory
GPU1 VRAM Size 12GB
GPU1 VRAM Type GDDR7
Integrated Graphics
GPU1 Graphics_Website Intel® Graphics
Memory
Memory Size 16GB*2
Memory Module DDR5
Memory(Slot) Max Speed Up to DDR5-6400
Memory Form NA
Memory Remark_Website *The actual frequency will vary by memory combination and CPU capability.
Memory Slot and Max Capacity
Memory Max Speed Up to DDR5-6400
Memory Slot 2 Slots
Memory Max Capacity_Website Max 128GB
Storage
SSD Form Factor M.2-2280 M-KEY
SSD Size 1TB*1
SSD Interface NVMe SSD PCIe Gen4
SSD 2 Size N/A
SSD 2 Interface N/A
HDD size N/A
2.5" HDD_Website N/A
SSD Remark N/A
Storage Slot
SSD (NVMe PCIe Gen)_Website 1x M.2 SSD slot (NVMe PCIe Gen4), 1x M.2 SSD slot (NVMe PCIe Gen5) Compatible
HDD_Website N/A
Max Storage Capacity 4TB
LAN
LAN_Website 2.5 Gigabit Ethernet
LAN REALTEK/RTL8125BG-CG
RJ45 1x
Wi-Fi/ Bluetooth
WLAN/BT_Website Intel® Wi-Fi 6E AX211, Bluetooth v5.3
WLAN Version Wi-Fi 6E+BT
WLAN/BT INTEL/AX211.NGWG.NV
USB Ports
Type-C (USB3.1 Gen2 / DP / Thunderbolt™3) N/A
Type-C (USB3.1 Gen2 / DP / Thunderbolt™3 optional) N/A
Type-C (USB3.2 Gen2 / DP / Thunderbolt™3) N/A
Type-C (USB3.2 Gen1 / DP / Thunderbolt™3) N/A
Type-C (USB3.2 Gen2 / DP / Thunderbolt™3) with PD charging N/A
Type-C (USB3.2 Gen2 / DisplayPort™) N/A
Thunderbolt™ 4 (DisplayPort™/ Power Delivery 3.0) N/A
Thunderbolt™ 4 (DisplayPort™/ Power Delivery 3.1) 1x
Thunderbolt™ 4 (DisplayPort™) N/A
Thunderbolt™ 5 (DisplayPort™/ Power Delivery 3.1) N/A
Thunderbolt™ (DisplayPort™/ Power Delivery 3.0) N/A
Type-C (USB4® / DisplayPort™/ Power Delivery 3.0/ Thunderbolt™ 4 compatible) NA
Type-C (USB4® / DisplayPort™/ Power Delivery 3.1/ Thunderbolt™ 4 compatible) N/A
Type-C (USB3.2 Gen2 / DisplayPort™/ Power Delivery 3.0) 1x
Type-C (USB3.2 Gen2 / DisplayPort™/ Power Delivery 3.1) NA
Type-C (USB3.2 Gen1 / DisplayPort™/ Power Delivery 3.0) N/A
Type-C (USB3.1 Gen1 / DisplayPort™) N/A
Type-C (USB3.2 Gen1 / DisplayPort™) N/A
Type-C USB3.1 Gen2 N/A
Type-C USB3.2 Gen2 N/A
Type-C USB3.2 Gen2 with PD charging N/A
Type-C USB3.1 Gen1 N/A
Type-C USB3.2 Gen1 N/A
Type-A USB3.1 Gen1 N/A
Type-A USB3.2 Gen1 N/A
Type-A USB3.1 Gen2 N/A
Type-A USB3.2 Gen2 3x
Type-C USB3.2 Gen2x2 N/A
Type-A USB2.0 N/A
USB3.2 Gen 2 Type-C(connect to computer) N/A
Card Reader
CardReader N/A
Smart Card Reader N/A
Video Ports
HDMI™ 1x HDMI™ 2.1 (8K @ 60Hz / 4K @ 120Hz)
DisplayPort N/A
Mini Display Port N/A
Keyboard
Keyboard Types_Website 24-Zone RGB Gaming Keyboard with Copilot Key
Keyboard Feature NA
Keyboard Keys 99KEYS
Key Travel 1.7
Keyboard Numeric Yes
Keyboard Color BLACK
Keyboard  Language CS Wleft Nokr
Touchpad
Touchpad NA
WebCam
WebCam HD type (30fps@720p) with 3D Noise Reduction (3DNR)
Audio Port
Audio Jack_Website 1x Mic-in/Headphone-out Combo Jack
Audio
Audio Speaker 2x 2W
Audio Woofer N/A
Audio Mic Array Microphone
Audio Solution_Website Hi-Res Audio Ready, Nahimic 3 Audio Enhancer
Adapter
Adaptor 240W
Adaptor Input 90-265Vin
Adaptor Unit Weight (g) 580
Adaptor Type N/A
Power Cord Unit Weight (g) 195
Power Cord Type EU
S0/S0ix PD charging range 65W~140W
S4/S5 PD charging range 15W~140W
Adaptor Remark N/A
Battery
Battery Type 4CELLS/4S1P
Battery Cell_Website 4-Cell
Whrs 80 Whrs
Mah 5120 Mah
Battery Unit Weight (g) 283.8
Support Fast Charging Yes
Operating Systems
OS N/A
OS Type Free DOS
OS_Website Free Dos
Copilot+ PC Certified N/A
Microsoft Office
OS-Office_Website N/A
Dimension (WXDXH)
Dimension 363 x 269.7 x 21.95 - 23.85 mm
Dimension(Inches)_Website 14.29" x 10.62" x 0.86 - 0.94"
Weight (W/ Battery)
Weight 2.2 (OLED) / 2.3 (IPS) kg
Weight(lbs)_Website 4.85 (OLED) / 5.07 (IPS) lbs
Security
Security Type_Website Firmware Trusted Platform Module(fTPM) 2.0, Kensington Lock, Webcam Shutter
Certification
Certification Type_Website NA
Sustainability
EPEAT_Website N/A
TCO Certified N/A
Energy Star 9.0 N/A
Sensor
Fingerprint N/A
Ambient Light Sensor_Website NA
Gyroscope_Website NA
Accelerometer_Website NA
Magnetometer_Website NA
Proximity Sensor NA
Adaptive Color Sensor NA
NFC N/A
Warranty
Warranty 24M
Warranty_Website 2 years limited warranty
Additional Warranty N/A
Xbox Game Pass
Xbox Game Pass N/A
Xbox Game Pass Remark N/A
Accessory
Extra Bag N/A
Extra Mouse N/A
Remark
Remark 1_Website
Software
Software AI Noise Cancellation Pro, Discrete Graphics Mode, MSI AI Engine, MSI App Player, MSI Center, Mystic Light, Nahimic 3, Nvidia App, True Color
Model Info
Segment Name2 Crosshair16MaxHXE
Segment Name CrosshairMax
Series Name Gaming
Segment Name3 Crosshair16MaxHXE2WGXK
EAN 4711377451222
